This product is designed in a modular design to provide users with different combinations of use requirements. The image-capable image module and pluggable design replace the current guide bars to provide users with safer use scenarios and modularization. Design allows the user to change as needed.



NeoPed Specification

Product Name Digital bronchoscope
Model C-T01
Dimension 90 x 200 x 80mm (approx.)
Weight 255 g (approx.)
LCD display 3" TFT LCD
Image resolution HVGA (400 x 400 pixels)
Image frame rate 30 fps
Functions Snapshot, video recording, image (Photo & video) review on LCD screen, photo & video transfer from flash memory to PC (or Mac)
IO Interface Micro USB 2.0 / AV out (2.5mm)
Power source Replaceable & rechargeable lithium battery
DC 3.78V, 2950mAh 11.15Wh
Brand & Model: NPT (BP-ICR18650-30)
Input rating DC 5.0V, 1A
Power adapter Brand & Model: SINGOF (SINGOF-10U-050200)
– AC in: 100-240V, 50/60Hz 0.3-0.12A
– DC out: 5.0V, 2A
File storage 4 GB memory
Photo storage format JPEG
Video recording  format MOV (MPEG4 compression)
Operating time 8 hours (average)
Charging time 4 hours (average)
Working condition – Ambient temperature: 0 ~ 40°C (23 ~ 104°F)
– Relative humidity: 5 ~ 80%
– Atmospheric pressure: 700 ~ 1060 hPa
Storage / transportation conditions – Ambient temperature: -10 ~ 65°C (14 ~ 149°F)
– Relative humidity: 5 ~ 80%
– Atmospheric pressure: 700 ~ 1060 hPa
